  • Cleanroom CR65 CAROUSEL

Cleanroom IP65 LED

EL-CR65L-5103-000

CLEANROOM IP65 LED Plaster/Sandwich panel Single Luminaire Bottom Access Direct 6000lm 40.4W LED Wide beam 4000K Ra90+ 240V Delta Non-dim Class I Std AUS flex & plug 2.0m L:680mm W:680mm H:100mm IP65 IK08/5J White .

Local manufacture
Eagle Lighting
  • Technical Overview

    Cleanroom IP65 Dimensions v1 300421
    • Finish
      White
    • L = Length [mm]
      680
    • W = Width/Diameter [mm]
      680
    • H = Height [mm]
      100
    • CL = Recessing Length [mm]
      -
    • CW = Recessing Width/Diameter [mm]
      -
    • Weight [kg]
      12
    Cleanroom IP65 polarcurve v1
    Nominal polar curve

  • Photometric Values

    • Control Type
      Non-dim
    • Wattage [W]
      40.4
    • CLO Enabled
      0
    • Final Wattage CLO [W]
      0
    • System Lumens
      6000
    • Luminaire Lumens [lm]
      4247
    • Efficacy [lm/W]
      105
    • Target Spacing [m]
      2.4x2.4
    • Target H Illuminance [lux]
      600
    • LPD [W/sqm]
      7.01
    • NPD [W/sqm/100lux]
      1.15
    • Beamwidth (FWHM)
      -
    • Optics Type
      Delta
    • UGR
      19
  • Emergency Parameters

    • Emergency Type
      -
    • Emergency Class
      -
  • Colour Quality

    • CCT [K]
      4000K
    • CCT1 [K]
      4000K
    • CCT2 [K]
      -
    • Other Light Colour
      -
    • CRI
      Ra90+
    • COI Compliance
      Compliant
    • R9
      68
    • Melanopic Ratio
      0.72
    • Circadian Stimulus CS [%]
      0
    • Circadian Light [lux]
      0
    • TM-30 RF
      91
    • TM-30 RG
      100
  • Lifetime and Miscellaneous Parameters

    • LM80 Test Duration [hrs]
      12000
    • L90B50 Lifetime (CLO) [hrs]
      -
    • TM21 L70 Reported Lifetime [hrs]
      -
    • L100B50 Lifetime (CLO) [hrs]
      -
    • TM21 L90 Reported Lifetime [hrs]
      -
    • SDCM Initial
      3
