ELLE Surface Mounted - Opal

Surface mounted version of our modular linear lighting system - designed, tested and manufactured in Melbourne.

Local manufacture

ELLE Surface Mounted - Opal

Eagle Lighting
ELLE SM OPAL WHITE CAROUSEL
  • OPAL GREY CAROUSEL
  • ELLE SM OPAL BLACK CAROUSEL
  • ELLE SM OPAL GREY CAROUSEL
Symbol LED
Symbol DIRECT LIGHT DISTRIBUTION
Symbol CLASS I
Symbol IP20
Symbol ORGANIC RESPONSE LOGO
Symbol CUSTOMISABLE
Symbol IES
Symbol RCM LOGO
UGR19v1

  • General Information

    General Information

    Date Updated: 24 January 2025

    APPLICATION

    Thanks to its design and customisation options, the range is ideal for a wide variety of environments, including offices, healthcare and education facilities, leisure/hospitality, retail/shopping centres, airport/rail circulation and commercial precinct.

    Whether you require purely decorative accent lighting or technically perfect office lighting, the ELLE range offers a version to suit any project.

    DESIGN

    ELLE is a flexible and modular product family which can be configured to a project's specific requirement based on application and interior design intent.

    • Single or continuous.

    A sustainable, energy-efficient system, ELLE provides significant advantages for developers and occupiers seeking to achieve WELL building and Greenstar Certification.

    OPTICS

    To learn more about ELLEs optics, download the brochure here.

    COLOUR OPTIONS

    ELLE's standard range of colour finishes powder coated in our state-of-the-art Melbourne Manufacturing facility include black, white and grey.

    These three colours are available in a textured powder-coated finish, with architectural metallic finishes also available upon request.

    LENGTHS

    Lengths are entirely driven by a project's specific requirement and configured using our 835mm, 1250mm and 2500mm module lengths accordingly.

    CONTROLS

    LIFETIME

    LIGHT QUALITY

    • Colour temperature: 3000K and 4000K.
    • CRI90+ standard for all versions.
    • COI (Cyanosis Observation Index) compliant.
    • Initial colour consistency better than 3 SDCM

    INSTALLATION & MOUNTING OPTIONS

    Continuous connection for fast installation and quality results.

    ELLE is supplied with most of the work completed during manufacturing, making it intuitive, fast and straightforward for the electrical installer. ELLE has been developed and refined to incorporate a pre-wired harness with a quick connect male/female electrical coupler connection. Continuous joins incorporate a “light trap” between the louvres eliminating light leakage at the profile and louvre joins.

    This supports contractors installing ELLE onto projects to run both under time and budget whilst delivering a high-quality finished result.

    ELLE is available as either Single pendants or continuous run installations via wire suspension or surface mounted. Installation via wire suspension requires wire brackets which provide flexible centres.

    N.B.

    • Codes and Data in the 'PRODUCT CODE' table below are for the white versions only
    • Images are a representation of product design; the finished product may vary slightly according to project specification etc.

    Key Family Details

    • Optical System:
      Opal diffuser
    • Mounting Type:
      Surface Mounted (Ceiling)
    • Finish:
      White, Black, and Grey
    • System Warranty:
      5 years
    • CRI (Ra):
      Ra90+
    • CCT:
      4000K
    • R9:
      ≥70
    • COI Compliant:
      Yes (≤1.9)
    • Melanopic Ratio:
      ≥0.7
    • Circadian Stimulus CS [%] (*):
      13
    • Circadian Light Cla [lux] (*):
      ≥90
    • N.B.
      (*) For 150lux corneal photopic illumination. As a guide only.

Product Code

PRODUCT CODEIES FILEControl/Wiring TypeLength [mm]Lighting TypeCeiling Type/MountingColour/FinishInstallationWattage [W]Final Wattage CLO [W]Luminaire Lumens [lm]CCT1 [K]CCT2 [K] L100B50 CLO [hrs]
Download IES FileEL-ELLS-1048-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattStart Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1051-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattContinuous Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1054-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattEnd Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1049-244-DALI835DirectSurface Mounted (Ceiling)Black MattStart Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1050-244-DALI835DirectSurface Mounted (Ceiling)Grey MattStart Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1052-244-DALI835DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1053-244-DALI835DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1055-244-DALI835DirectSurface Mounted (Ceiling)Black MattEnd Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1056-244-DALI835DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire8.497984000K-50000
Download IES FileEL-ELLS-1057-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattStart Luminaire10119594000K-50000
Download IES FileEL-ELLS-1060-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattContinuous Luminaire10119594000K-50000
Download IES FileEL-ELLS-1063-244Download IES FileDALI835DirectSurface Mounted (Ceiling)White MattEnd Luminaire10119594000K-50000
Download IES FileEL-ELLS-1058-244-DALI835DirectSurface Mounted (Ceiling)Black MattStart Luminaire10119594000K-50000
Download IES FileEL-ELLS-1059-244-DALI835DirectSurface Mounted (Ceiling)Grey MattStart Luminaire10119594000K-50000
Download IES FileEL-ELLS-1061-244-DALI835DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire10119594000K-50000
Download IES FileEL-ELLS-1062-244-DALI835DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire10119594000K-50000
Download IES FileEL-ELLS-1064-244-DALI835DirectSurface Mounted (Ceiling)Black MattEnd Luminaire10119594000K-50000
Download IES FileEL-ELLS-1065-244-DALI835DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire10119594000K-50000
Download IES FileEL-ELLS-1015-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattStart Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1018-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattContinuous Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1021-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattEnd Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1016-244-DALI1250DirectSurface Mounted (Ceiling)Black MattStart Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1017-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattStart Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1019-244-DALI1250DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1020-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1022-244-DALI1250DirectSurface Mounted (Ceiling)Black MattEnd Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1023-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire10.91211834000K-50000
Download IES FileEL-ELLS-1359-244-DALI898DirectSurface Mounted (Ceiling)White MattCorner R Con11.1129184000K-50000
Download IES FileEL-ELLS-1360-244-DALI898DirectSurface Mounted (Ceiling)Black MattCorner R Con11.1129184000K-50000
Download IES FileEL-ELLS-1361-244-DALI898DirectSurface Mounted (Ceiling)Grey MattCorner R Con11.1129184000K-50000
Download IES FileEL-ELLS-1362-244-DALI898DirectSurface Mounted (Ceiling)White MattCorner L Con11.1129184000K-50000
Download IES FileEL-ELLS-1363-244-DALI898DirectSurface Mounted (Ceiling)Black MattCorner L Con11.1129184000K-50000
Download IES FileEL-ELLS-1364-244-DALI898DirectSurface Mounted (Ceiling)Grey MattCorner L Con11.1129184000K-50000
Download IES FileEL-ELLS-1365-244-DALI898DirectSurface Mounted (Ceiling)White MattCorner R Sta11.1129184000K-50000
Download IES FileEL-ELLS-1366-244-DALI898DirectSurface Mounted (Ceiling)Black MattCorner R Sta11.1129184000K-50000
Download IES FileEL-ELLS-1367-244-DALI898DirectSurface Mounted (Ceiling)Grey MattCorner R Sta11.1129184000K-50000
Download IES FileEL-ELLS-1368-244-DALI898DirectSurface Mounted (Ceiling)White MattCorner R Sta-C11.1129184000K-50000
Download IES FileEL-ELLS-1369-244-DALI898DirectSurface Mounted (Ceiling)Black MattCorner R Sta-C11.1129184000K-50000
Download IES FileEL-ELLS-1370-244-DALI898DirectSurface Mounted (Ceiling)Grey MattCorner R Sta-C11.1129184000K-50000
Download IES FileEL-ELLS-1006-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattStart Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1009-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattContinuous Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1012-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattEnd Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1007-244-DALI1250DirectSurface Mounted (Ceiling)Black MattStart Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1008-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattStart Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1010-244-DALI1250DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1011-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1013-244-DALI1250DirectSurface Mounted (Ceiling)Black MattEnd Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1014-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire13.21514724000K-50000
Download IES FileEL-ELLS-1000-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattSingle Luminaire20.92323524000K-50000
Download IES FileEL-ELLS-1001-244-DALI1250DirectSurface Mounted (Ceiling)Black MattSingle Luminaire20.92323524000K-50000
Download IES FileEL-ELLS-1002-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattSingle Luminaire20.92323524000K-50000
Download IES FileEL-ELLS-1030-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattStart Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1033-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattContinuous Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1036-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattEnd Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1031-244-DALI2500DirectSurface Mounted (Ceiling)Black MattStart Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1032-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattStart Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1034-244-DALI2500DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1035-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1037-244-DALI2500DirectSurface Mounted (Ceiling)Black MattEnd Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1038-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire21.72423664000K-50000
Download IES FileEL-ELLS-1003-244Download IES FileDALI1250DirectSurface Mounted (Ceiling)White MattSingle Luminaire24.32727534000K-50000
Download IES FileEL-ELLS-1004-244-DALI1250DirectSurface Mounted (Ceiling)Black MattSingle Luminaire24.32727534000K-50000
Download IES FileEL-ELLS-1005-244-DALI1250DirectSurface Mounted (Ceiling)Grey MattSingle Luminaire24.32727534000K-50000
Download IES FileEL-ELLS-1039-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattStart Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1042-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattContinuous Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1045-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattEnd Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1040-244-DALI2500DirectSurface Mounted (Ceiling)Black MattStart Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1041-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattStart Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1043-244-DALI2500DirectSurface Mounted (Ceiling)Black MattContinuous Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1044-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattContinuous Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1046-244-DALI2500DirectSurface Mounted (Ceiling)Black MattEnd Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1047-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattEnd Luminaire26.42929444000K-50000
Download IES FileEL-ELLS-1024-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattSingle Luminaire41.84647044000K-50000
Download IES FileEL-ELLS-1025-244-DALI2500DirectSurface Mounted (Ceiling)Black MattSingle Luminaire41.84647044000K-50000
Download IES FileEL-ELLS-1026-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattSingle Luminaire41.84647044000K-50000
Download IES FileEL-ELLS-1027-244Download IES FileDALI2500DirectSurface Mounted (Ceiling)White MattSingle Luminaire48.25355064000K-50000
Download IES FileEL-ELLS-1028-244-DALI2500DirectSurface Mounted (Ceiling)Black MattSingle Luminaire48.25355064000K-50000
Download IES FileEL-ELLS-1029-244-DALI2500DirectSurface Mounted (Ceiling)Grey MattSingle Luminaire48.25355064000K-50000
Accessories


ELLE ORGANIC RESPONSE MODULES

ELLE Surface Mounted / Pendant ORT Modules
ELLE Surface Mounted / Pendant ORT Modules

EL-ELLA-1000-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 White Matt Continuous 2 Way. Connects DALI In Both Directions

EL-ELLA-1001-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Black Matt Continuous 2 Way. Connects DALI In Both Directions

EL-ELLA-1002-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Grey Matt Continuous 2 Way. Connects DALI In Both Directions

EL-ELLA-1003-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 White Matt Continuous Right. Connects DALI In Right Direction and Breaks DALI to the Left

EL-ELLA-1004-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Black Matt Continuous Right. Connects DALI In Right Direction and Breaks DALI to the Left

EL-ELLA-1005-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Grey Matt Continuous Right. Connects DALI In Right Direction and Breaks DALI to the Left

EL-ELLA-1006-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 White Matt Continuous Left. Connects DALI In Left Direction and Breaks DALI to the Right

EL-ELLA-1007-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Black Matt Continuous Left. Connects DALI In Left Direction and Breaks DALI to the Right

EL-ELLA-1008-974

ELLE ORT MODULE SM/Pendant Opal/Delta L:200mm IP20 Grey Matt Continuous Left. Connects DALI In Left Direction and Breaks DALI to the Right

EL-ELLA-1018-974

ELLE ORT MODULE SM/Pendant Opal/Delta Extender L:200mm IP20 White Matt

EL-ELLA-1019-974

ELLE ORT MODULE SM/Pendant Opal/Delta Extender L:200mm IP20 Grey Matt

EL-ELLA-1020-974

ELLE ORT MODULE SM/Pendant Opal/Delta Extender L:200mm IP20 Black Matt
Note: Each ORT module is for use with up to 4 ELLE DALI sections in continuous installation.

ELLE EMERGENCY MODULES

ELLE EMG Module
ELLE EMG Module
EL-ELLA-1800-800ELLE EMG MODULE SM/Pendant Opal/Delta/Beta Maintained, Non-Monitored Class I L:600mm IP20 White Matt
EL-ELLA-1800-801ELLE EMG MODULE SM/Pendant Opal/Delta/Beta DALI Maintained, DALI-Monitored Class I L:600mm IP20 White Matt
EL-ELLA-1801-800ELLE EMG MODULE SM/Pendant Opal/Delta/Beta Maintained, Non-Monitored Class I L:600mm IP20 Black Matt
EL-ELLA-1801-801ELLE EMG MODULE SM/Pendant Opal/Delta/Beta DALI Maintained, DALI-Monitored Class I L:600mm IP20 Black Matt
EL-ELLA-1802-800ELLE EMG MODULE SM/Pendant Opal/Delta/Beta Maintained, Non-Monitored Class I L:600mm IP20 Grey Matt
EL-ELLA-1802-801
ELLE EMG MODULE SM/Pendant Opal/Delta/Beta DALI Maintained, DALI-Monitored Class I L:600mm IP20 Grey Matt

ELLE SPACER MODULES

ELLE Surface Mounted Spacer
ELLE Surface Mounted Spacer
EL-ELLS-1400-244
ELLE Spacer Surface Mounted Opal/Delta / L:400mm IP20 White Matt
EL-ELLS-1401-244
ELLE Spacer Surface Mounted Opal/Delta / L:400mm IP20 Black Matt
EL-ELLS-1402-244
ELLE Spacer Surface Mounted Opal/Delta / L:400mm IP20 Grey Matt
EL-ELLS-1403-244
ELLE Spacer Surface Mounted Opal/Delta / L:600mm IP20 White Matt
EL-ELLS-1404-244
ELLE Spacer Surface Mounted Opal/Delta / L:600mm IP20 Black Matt
EL-ELLS-1405-244
ELLE Spacer Surface Mounted Opal/Delta / L:600mm IP20 Grey Matt
EL-ELLS-1406-244
ELLE Spacer Surface Mounted Opal/Delta / L:800mm IP20 White Matt
EL-ELLS-1407-244
ELLE Spacer Surface Mounted Opal/Delta / L:800mm IP20 Black Matt
EL-ELLS-1408-244
ELLE Spacer Surface Mounted Opal/Delta / L:800mm IP20 Grey Matt
EL-ELLS-1409-244
ELLE Spacer Surface Mounted Opal/Delta / L:1200mm IP20 White Matt
EL-ELLS-1410-244
ELLE Spacer Surface Mounted Opal/Delta / L:1200mm IP20 Black Matt
EL-ELLS-1411-244
ELLE Spacer Surface Mounted Opal/Delta / L:1200mm IP20 Grey Matt
