OmniPOD Linear
EL-OMN-2198-954
OMNIPOD LINEAR Recessed/T-bar Single Luminaire Bottom Access Direct 3300lm 23W LED Wide beam 4000K Ra90+ 240V Hybrid Organic Response Class II Std AUS flex & plug 2.0m L:1193mm W:294mm H:38mm IP40 White body/ White Pods .
-
Technical Overview
-
Finish
White body/ White Pods -
L = Length [mm]
1193 -
W = Width/Diameter [mm]
294 -
H = Height [mm]
38 -
CL = Recessing Length [mm]
- -
CW = Recessing Width/Diameter [mm]
- -
Weight [kg]
4.8
Normalised Polar Curve (white pods)
Normalised Polar Curve (black pods)
-
-
Photometric Values
-
Control Type
Organic Response -
Ceiling Type/Mounting
Recessed/T-bar -
Wattage [W]
23 -
CLO Enabled
Yes -
Final Wattage CLO [W]
29 -
System Lumens [lm]
3300 -
Luminaire Lumens [lm]
2519 -
Efficacy [lm/W]
108
-
Lighting Type
Direct -
Target Spacing [m]
2.4 x 2.4 -
Target H Illuminance [lux]
410 -
LPD [W/m2]
5.04 -
NPD [W/sqm/100lux]
1.25 -
Beamwidth (FWHM)
- -
Optics Type
Hybrid -
UGR
19
-
-
Colour Quality
-
CCT [K]
4000K -
CCT1 [K]
4000K -
CCT2 [K]
- -
Other Light Colour
- -
CRI
Ra90+ -
COI Compliance
Non-Compliant -
CLA 2.0
- -
M-DER
-
-
R9
58 -
Melanopic Ratio
0.67 -
Circadian Stimulus CS [%]
11 -
Circadian Light [lux]
80 -
TM-30 RF
90 -
TM-30 RG
99 -
M-EDI
-
-
-
Lifetime and Miscellaneous Parameters
-
LM80 Test Duration [hrs]
12000 -
L90B50 Lifetime [hrs]
65000 -
TM21 L70 Reported Lifetime [hrs]
-
-
L100B50 Lifetime (CLO) [hrs]
72000 -
TM21 L90 Reported Lifetime [hrs]
- -
SDCM Initial
3
-
Accessories
| CODE | DESCRIPTION |
| EL-ACC-210-000 | Restraint Kit - 4 x gripple, 2 x 2m wire |
| EL-ACC-873-000 | Surface mount kit 600X300X50 T/S ET OMNIPOD |
| EL-ACC-874-000 | Surface mount kit 1200X300X50 T/S ET OMNIPOD |
| EL-ACC-875-000 | Surface mount kit 1500X300X50 T/S ET OMNIPOD |
| EL-ACC-850-000 | Plaster recess kit 600x300 |
| EL-ACC-852-000 | Plaster recess kit 1200x300 |
| EL-ACC-853-000 | Plaster recess kit 1500x300 |
| CODE | DESCRIPTION |
| EL-ACC-180-000 | Casambi Wireless User Interface (Battery powered. 4 scenes. Available in White or Black) |
| EL-ACC-181-000 | DALI Touch Panel Basic TW (Capacitive DALI touch panel with real glass display) |
| EL-ACC-182-000 | DALI x/e-touchPANEL 02 (Touch-screen based DALI lighting and emergency lighting management system) |
| EL-ACC-183-000 | Tridonic DALI XC (DALI input controller) |
