  • Cirkel Square Fixed CAROUSEL

Cirkel Square Fixed

Cirkel is a family of versatile LED downlights for use in commercial, retail and various other indoor applications. MOQ 100.

Custom Datasheet

Optional: Enter your details for the document header

Eagle Lighting Logo colour

Cirkel Square Fixed

Eagle Lighting
Cirkel Square Fixed CAROUSEL
Symbol LED
Symbol DIRECT LIGHT DISTRIBUTION
Symbol DO NOT INSULATE
Symbol IP65
Symbol CLASS II
Symbol RCM LOGO
Symbol IES
Symbol REVIT

  • General Information

    General Information

    Please note, minimum order quantities of 100 apply.

    APPLICATION
    Cirkel is a family of versatile LED downlights for use in commercial, retail and various other indoor applications.

    The full range consists of nearly 200 models with a range of power, CCT, beam and control options as well as various finish and body types to make sure you can find the right fitting for your project.

    The fixed beam versions of the family are IP65 certified and exceed the requirements for wet locations such as bathrooms and shower areas.

    DESIGN
    The Square Fixed sub-range consists of recessed downlights with square flange.

    OPTICS
    Lens with 24°, 36° and 60° (FWHM) beam options.

    CONTROL
    On/Off and DALI.

    INSTALLATION
    A circular cutout of Ø75mm is required.

    LIFETIME
    TM21 L70 > 50,000 hours for all models in the range.

    LIGHT QUALITY
    The range is CRI 90+ with R9>50 as standard.

    NOTES
    CCT 4000K variants are COI compliant.

    Key Family Details

    • Optical System:
      24,36 and 60 degrees (FWHM) lens options
    • Mounting Type:
      Recessed
    • Colour Consistency Initial:
      3 SDCM
    • Finish Options:
      Black and White
    • System Warranty:
      5 years
    • CRI (Ra):
      90+
    • CCT:
      3000K and 4000K
    • R9:
      50+
    • COI Compliant:
      4000K only, =<2.5
    • Melanopic Ratio:
      0.51 - 0.71
    • Circadian Stimulus CS [%] (*):
      10 - 20
    • Circadian Light Cla [lux] (*):
      72 - 153
    • (*):
      For 150lux corneal illumination. As a guide only.
